What is YSLY Flexible PVC Control Cable?
YSLY cables are suitable for permanent and mobile installations. They are appropriated to be used indoor, signaling, and service connection in tool machines. The sheath of these cables has excellent resistance properties to abrasion, humidity, impact as well as to mineral oils for general use.
Electrical Characteristics
- Rated Voltage: 300/500 V
- Test voltage: 3000V
- Max conductor temperature: +70℃ during operation, +150°C in the case of a short circuit
- Min. insulation resistance: 20 MΩOhm x km
- Breakdown voltage: Min.6000 V
Design Specifications
- Conductor: Bare copper, Class 5 according to EN 60228
- Insulation: PVC type TI2
- Sheathing Material: PVC type TM2 or TM 5 – oil resistant (Colour Grey)
Dimensions
| Conductor Cross Section (mm²) | Core No. | Nominal Outer Diameter (mm) | Max. Conductor Resistance (Ω/km) | Rated Voltage (V) | Test Voltage(V) | Reference Weight (kg/km) |
| 0.5 | 2-24 | 5.2 – 10.8 | 39 | 300/500 | 2000 | 43 – 230 |
| 0.75 | 2-24 | 5.6 – 12.8 | 26 | 300/500 | 2000 | 52 – 290 |
| 1 | 2-24 | 6.0 – 14.5 | 19.5 | 450/750 | 2500 | 65 – 340 |
| 1.5 | 2-24 | 6.7 – 17.2 | 13.3 | 450/750 | 2500 | 85 – 470 |
| 2.5 | 2-24 | 7.8 – 21.8 | 7.98 | 450/750 | 2500 | 120 – 680 |
| 4 | 2-12 | 9.2 – 24.0 | 4.95 | 450/750 | 2500 | 170 – 890 |
| 6 | 2-12 | 10.8 – 28.5 | 3.3 | 450/750 | 2500 | 250 – 1180 |
| 10 | 2-7 | 13.0 – 34.2 | 1.91 | 450/750 | 2500 | 400 – 1700 |
| 16 | 2-7 | 15.2 – 41.2 | 1.21 | 450/750 | 2500 | 600 – 2450 |
| 25 | 2-5 | 18.5 – 49.0 | 0.78 | 450/750 | 2500 | 940 – 3300 |
