This product can be manufactured with ethylene propylene rubber (EPR) insulation, cross-linked polyethylene (XLPE) insulation, polyvinyl chloride (PVC) insulation, or natural-butadiene rubber insulation to produce marine power cables. It is mainly suitable for power, lighting, and general control systems in various river and sea vessels, offshore oil platforms, and other waterborne structures.
CJPF86/SC Marine Cable Specifications
The CJPF86/SC marine cable is suitable for power systems with a rated voltage U0/U of 0.6/1kV and below.
Usage Characteristics
Operating Temperature
- EPR insulated marine power cables: 90°C
- XLPE insulated marine power cables: 90°C
- PVC insulated marine power cables: 70°C
- Natural-butadiene rubber insulated marine power cables: 65°C
Short-Circuit Temperature (Maximum duration 5 seconds)
- EPR insulated marine power cables: 250°C
- XLPE insulated marine power cables: 250°C
- PVC insulated marine power cables: 150°C
- Natural-butadiene rubber insulated marine power cables: 150°C
Installation Temperature and Minimum Bending Radius
- XLPE and PVC insulated cables:
- Installation temperature: Not below 0°C
- Minimum bending radius: 20D (single-core), 15D (multi-core), where D is the cable outer diameter
- EPR and natural-butadiene rubber insulated cables:
- Installation temperature: Not below 0°C
- Minimum bending radius: 10D (single-core), 6D (multi-core), where D is the cable outer diameter
Marine Cable Models and Names
Common Models of EPR Insulated Marine Power Cables
| Product Model | Product Name |
|---|---|
| CEF/DA/SA/NA, CEF80/DA/SA/NA, CEF82/DA/SA/NA, CEF90/DA/SA/NA, CEF92/DA/SA/NA, CEFR/DA/SA/NA | EPR insulated chloroprene sheathed marine power cable, DA/SA/NA type |
| CEH/DA/SA/NA, CEH80/DA/SA/NA, CEH90/DA/SA/NA, CEH82/DA/SA/NA, CEH92/DA/SA/NA, CEHR/DA/SA/NA | EPR insulated chlorosulfonated polyethylene sheathed marine power cable, DA/SA/NA type |
| CEV/DA/SA/NA, CEV80/DA/SA/NA, CEV90/DA/SA/NA, CEV92/DA/SA/NA, CEV82/DA/SA/NA, CEVR/DA/SA/NA | EPR insulated PVC sheathed marine power cable, DA/SA/NA type |
| CEPF/SC/NC/NSC, CEPF80/SC/NC/NSC, CEPF86/SC/NC/NSC, CEPF90/SC/NC/NSC, CEPF96/SC/NC/NSC, CEPFR/SC/NC/NSC | Halogen-free low-smoke EPR insulated thermoplastic polyolefin sheathed flame-retardant marine power cable, SC/NC/NSC type |
| CEPJ/SC/NC/NSC, CEPJ80/SC/NC/NSC, CEPJ85/SC/NC/NSC, CEPJ90/SC/NC/NSC, CEPJ95/SC/NC/NSC, CEPJR/SC/NC/NSC | Halogen-free low-smoke EPR insulated cross-linked polyolefin sheathed flame-retardant marine power cable, SC/NC/NSC type |
Note: Cable models not listed in the table can be composed according to the provisions of Q/NPDL035-2006 standard.
