40-Core Flexible Cable — High-Density Multi-Conductor Flex Cable for Complex Signal, Control, and Data Acquisition in Moving Carriers

40-core flexible cable: 40 conductors in a single compact sheath for high-density control and signal wiring in drag chains and mobile carriers. IEC 60228 Class 5 fine stranded copper, 0.14–0.5 mm² per core. PVC or PUR jacket, numbered core identification per VDE 0293. 300/300 V rated, 3–5 million flex cycles at 10×D. PET fleece layer-separated stranding prevents internal core abrasion. For PLC I/O, multi-sensor arrays, data acquisition, and complex machine wiring.

Key Features

40 individually numbered conductors in a single flexible sheath — replace multiple separate cables
IEC 60228 Class 5 fine stranded copper: 0.14–0.50 mm² per core — signal and low-power control rated
Layered stranding with PET fleece separators: 3–4 concentric layers prevent internal core abrasion
Black cores with white consecutive numbering (1–40) per VDE 0293 — unambiguous identification at both ends
Compact design: typical OD 14–18 mm for 40 × 0.25 mm² — fits standard PG16/PG21 cable glands
PVC or PUR jacket: PVC for indoor economy; PUR for oil, UV, and outdoor environments
300/300 V rated — designed for control signals, sensors, and low-voltage power
Flame retardant per IEC 60332-1-2; RoHS and REACH compliant

Applications

PLC remote I/O wiring — 40 signals in one cable instead of 4 × 10-core cablesMulti-sensor arrays — temperature, pressure, proximity, and limit switch wiring on complex machineryData acquisition systems — multiplexed analog and digital signals from test rigsMachine control panels — flexible connection between moving operator consoles and fixed cabinetsAutomated test equipment — high-density signal routing in moving test heads and fixturesPackaging and converting machinery — complex multi-actuator control with limited carrier spaceStage and event rigging — multi-channel DMX, sensor, and control wiring in moving truss systems

Technical Specifications

Conductor Configuration 40 cores, bare copper, IEC 60228 / VDE 0295 Class 5 fine stranded
Conductor Cross-Sections 0.14 mm², 0.25 mm², 0.34 mm², 0.50 mm²
Conductor Construction 7-strand bunch (0.14–0.25 mm²); 19-strand bunch (0.34–0.50 mm²)
Core Insulation PVC (standard) or PP (low-capacitance for long runs)
Insulation Wall Thickness 0.2–0.3 mm (thin-wall for high density packing)
Core Identification Black cores with white consecutive numbering 1 through 40
Core Color (Alternate) Color coded per DIN 47100 with repeating sequences
Stranding Structure 3–4 concentric layers with PET fleece wrapping between each layer
Central Filler PP or jute yarn — provides round substrate for inner layer
Filler Elements PP yarn in outer interstices — creates round, stable cable geometry
Inner Wrap PET non-woven tape over outermost core layer
Outer Jacket — PVC PVC, Shore 85–90 A; gray RAL 7001 or black RAL 9005
Outer Jacket — PUR PUR, Shore 85–90 A; gray RAL 7001; halogen-free; oil/UV rated
Rated Voltage U₀/U 300/300 V (signal/low-power); 300/500 V on request
Test Voltage 1 500 V AC / 5 min (core-core)
Insulation Resistance ≥20 MΩ × km (at 20°C)
Current Rating (0.14 mm²) ~1.5 A per core at 30°C (signal only)
Current Rating (0.50 mm²) ~4 A per core at 30°C (low-power control)
Temperature Range (PVC · Moving) -5°C to +70°C
Temperature Range (PVC · Fixed) -30°C to +80°C
Temperature Range (PUR · Moving) -30°C to +80°C
Temperature Range (PUR · Fixed) -40°C to +80°C
Minimum Bend Radius (Moving) 10 × outer diameter
Minimum Bend Radius (Fixed) 5 × outer diameter
Typical Outer Diameter (40 × 0.25 mm²) 14.0–16.5 mm
Flex Life 3–5 million cycles (tested at 10×D, 25°C)
Flame Retardant IEC 60332-1-2
Oil Resistance PVC: limited; PUR: excellent (IEC 60811-404)
UV Resistance PUR: excellent (DIN EN ISO 4892-2); PVC: limited
Halogen-Free PUR jacket (IEC 60754-1)
Certifications CE, RoHS, REACH

Detailed Description

Why 40 Cores? The Density Economics of Multi-Conductor Cable

Running 40 individual single-core cables through a drag chain is impractical — the bundle would exceed carrier cross-section limits, the cables would tangle, and the installation labor would be prohibitive. Running 4 × 10-core cables is better, but still requires managing 4 separate cables that can twist around each other.

A single 40-core cable solves all three problems at once:

  • Carrier space: A 16 mm OD cable carries 40 signals in ~200 mm² of cross-section. Four 10-core cables at 10 mm OD each would occupy ~315 mm² — 57% more space
  • Installation labor: One cable pull and one set of terminations vs four. For a 20 m carrier run, this saves approximately 2–3 hours of installation time
  • Organization: One numbered sheath vs four cables to label, bundle, and manage. No risk of mixing up "cable A" and "cable B" during maintenance

High-Density Stranding — Engineering Compact Reliability

Packing 40 cores into a round cable requires precise stranding geometry. The standard structure:

Layer Structure

  • Central filler: PP or jute yarn, ~3 mm diameter — provides a round, stable substrate
  • Layer 1 (inner): 6–8 cores stranded around the central filler with short lay length
  • PET fleece wrap: Thin non-woven tape separates Layer 1 from Layer 2 — prevents core abrasion between layers
  • Layer 2 (middle): 12–14 cores stranded counter-direction to Layer 1
  • PET fleece wrap: Second separation layer
  • Layer 3 (outer): 16–20 cores stranded counter-direction to Layer 2
  • Final PET wrap: Overall inner wrap before jacket extrusion
The alternating stranding direction between layers is critical — it prevents the cable from developing a "memory" that would cause it to coil in one direction when unspooled.

Thin-Wall Insulation

Standard PVC insulation for power cables is 0.5–0.8 mm thick. For 40-core signal cables, the insulation is reduced to 0.2–0.3 mm — still providing >1 500 V dielectric strength, but significantly reducing the overall cable diameter. This is possible because the cores carry low-voltage signals (typically 24 V DC), not mains power.

Core Identification — Reading 40 Numbers

With 40 cores in one sheath, unambiguous identification at both ends is mandatory. Two systems are used:

Option 1: Printed Numbers (VDE 0293 Standard)

Black cores with white ink-jet printed numbers 1 through 40. Each core is individually readable. This is the standard for European machine wiring.

Option 2: Color Coding (DIN 47100)

Colors repeat in sequence: white, brown, green, yellow, gray, pink, blue, red, black, violet, gray-pink, red-blue, white-green, brown-green, white-yellow, yellow-brown, white-gray, gray-brown, white-pink, pink-brown — then repeat. 40 cores typically use 2 color sequences of 20 colors each, distinguished by a printed ring or stripe on the second sequence.

Recommendation: Use printed numbers for permanent installations where the cores terminate at numbered terminals. Use color coding for mobile/portable applications where the cable may be re-terminated and the numbered sequence could be disrupted.

When 40-Core Is the Right Choice

If Your Application...Then Consider...
30–45 signal points✅ 40-core is optimal (some spare)
15–25 signal points25-core or 2 × 12-core may be more cost-effective
50+ signal points2 × 25-core or 40-core + 12-core combination
Mixed power (2.5 mm²) and signal (0.25 mm²)Composite cable with mixed gauges — not 40 equal cores
High-speed data (Ethernet, CAN)Dedicated data cable — do not bundle in 40-core

Installation — Managing 40 Wires at Termination

Terminating a 40-core cable requires planning:

  • Label BEFORE cutting to length: Confirm all 40 numbers are visible along the entire cable before installation. A single missing number becomes a time-consuming tracing exercise at termination
  • Terminal block layout: Pre-print a terminal block layout diagram with core numbers mapped to terminal positions. Laminated A4 sheet at the panel door — the technician should never have to guess
  • Service loop: Leave a 300–500 mm service loop at each end. If a core is accidentally cut too short during termination, the service loop provides slack for re-termination without replacing the entire cable
  • Ground unused cores: Any cores not used in the current configuration should be grounded at one end. Floating unused cores can capacitively couple noise into active signal cores
  • Strain relief at both ends: Use a cable gland with integrated strain relief — 40 × 0.25 mm² cores collectively have minimal tensile strength. Clamping the jacket in a standard PG gland without strain relief will eventually pull out

Why Choose Yichi Cable 40-Core?

  • Layer-separated stranding: PET fleece between every conductor layer is standard — prevents the internal abrasion that causes inter-layer short circuits in high-density cables
  • Number verification: Every production batch is tested for sequential core numbering — no missing numbers, no duplicate numbers, no illegible printing
  • Thin-wall insulation reliability: Our PVC and PP thin-wall insulation is production-tested for pinhole-free extrusion before stranding — a single pinhole in a 40-core cable means scrapping the entire cable after termination
  • Compact OD: 14–18 mm OD for 40 × 0.25 mm² — fits standard industrial glands without adapters
  • Custom core mix: Need 20 × 0.25 mm² + 10 × 0.50 mm² + 10 × 0.14 mm² in one cable? We build mixed-gauge multi-core to your specification
