Marine Communication Cables – Shipboard Signal & Data Cables (IEC 60092-376)
Designed for signal transmission in shipboard and offshore platform telecom, computer, and information processing systems, our marine communication cables also serve as connecting lines for precision instrumentation, video links, telephone circuits, and control signal loops. These cables are engineered to withstand the harshest marine environments — offering superior resistance to corrosion, flame, oil, moisture, and seawater.
Manufactured in full compliance with the latest IEC 60092-350:2020 (general construction and test requirements for shipboard power, control and instrumentation cables) and IEC 60092-376:2017 (cables for control and instrumentation circuits up to 150/250V (300V)), our cables are the trusted choice for marine electrical engineering professionals worldwide.
Key Features & Construction
- Conductor: Stranded oxygen-free copper (OFC) — ensures high conductivity, signal integrity and flexibility during installation.
- Insulation: Ethylene Propylene Rubber (EPR) — excellent heat resistance and dielectric performance, rated for continuous conductor operation at 90 °C.
- Outer Sheath: Heavy-duty rubber compound (multiple options available, e.g., chloroprene/CR, chlorosulfonated polyethylene/CSM). Provides robust resistance to oil, seawater, abrasion and flame.
- Armoring: Galvanized steel wire braid or steel tape armor available for mechanical protection (optional, specified at order stage).
- Environmental Resistance: Moisture-proof, corrosion-resistant, flame retardant and fire-resistant construction. Suitable for enclosed engine rooms, deck areas and offshore installations.
- Cable Type Codes: CHEFR, CHEPJR, CHEPFR and other configurations to suit various sheathing and armouring requirements.
Technical Specifications
| Parameter | Detail |
|---|---|
| Rated Voltage | 150/250V, 300V (other voltages on request) |
| Max. Conductor Temperature | 90 °C |
| Applicable Standards | IEC 60092-350:2020, IEC 60092-376:2017 |
| Conductor Material | Stranded bare oxygen-free copper |
| Insulation | EPR (Ethylene Propylene Rubber) |
| Sheath | Rubber (CR, CSM or custom compound) |
| Armour | Optional – galvanized steel wire braid/tape |
| Fire Performance | Flame retardant, fire resistant (FR) available |
| Specialty Properties | Oil resistant, seawater resistant, moisture proof, anti-corrosion |
Typical Applications
- Shipboard telephone, public address and internal communication networks
- Video surveillance (CCTV) and data links for offshore platforms and vessels
- Control and instrumentation signal loops in machinery spaces and on deck
- Marine electronics, computer networking and information processing equipment
- Precision measurement and sensor connection lines exposed to severe marine conditions
Frequently Asked Questions
What voltage ratings are available for these shipboard communication cables?
Our standard marine communication cables are rated 150/250V and 300V, in accordance with IEC 60092-376. If your project requires a different voltage, custom designs can be provided.
Do your cables have type approval from classification societies such as ABS, DNV or LR?
Yes. We can supply marine communication cables with type approval certificates from major classification societies — including ABS, DNV, LR, BV and CCS — upon request. Please mention your certification needs when you inquire, and we will assist with the documentation.
What materials make the cable flame resistant and oil resistant?
The conductors are insulated with EPR (Ethylene Propylene Rubber), which is inherently heat resistant and suitable for continuous 90 °C operation. The outer rubber sheath — typically chloroprene (CR) or chlorosulfonated polyethylene (CSM) — provides excellent resistance to oil, seawater, and flame propagation. Fire-resistant constructions and low-smoke halogen-free (LSZH) compounds are also available.
Can I get an armoured version of the marine communication cable?
Absolutely. Galvanized steel wire braid or steel tape armour can be added to enhance mechanical protection. A non-armoured design is standard; specify your armouring preference when requesting a quotation.
What is the minimum order quantity and usual delivery time?
Minimum order quantities depend on the specific cable design, but we typically accept orders from 500 metres per size. Standard production lead time is 2–4 weeks; expedited manufacturing can often be arranged. Contact our engineering sales team for a detailed quote and delivery schedule.
Request a quote today — tell us your cable specification, required ship classification approvals and delivery destination. Our team is ready to support your newbuilding, retrofit, or MRO project.
